Underwater Pan Tilt Camera

Name: Underwater Pan tilt Camera
Brand: Granfoo
SKU: 40193132

Product Features
1. Built-in encoder, external decoder, let the field cable more unitary, bid farewell to the traditional network connection;
2. Customized version of one-way sealed watertight connector; pressure level up to 3000 meters,
3. Enjoy the warranty 1 year, life-long maintenance.

Send Inquiry

Description

Underwater Pan Tilt Camera

GLF-UDC-DN200 uses 1 / 2.8 "CMOS progressive scan imaging sensor, 36x optical zoom electric zoom lens. Shell aluminum (fresh water); titanium alloy (seawater) material can be arbitrarily selected according to customer requirements, support pressure 300 meters. Underwater pan tilt camera(GLF-UDC-DN200) is very suitable for integration into ROV and other deep-sea applications.

Underwater camera GLF-UDC-12A.jpg underwater camera waterproof connector.jpg

GLF-UNC-12A (L / T) Underwater Network HD camera can be connected with underwater robot, high output LED light

To form a complete Glan floating underwater video system.

Main Features.png

1. Underwater pan tilt camera(GLF-UDC-DN200) built-in encoder, external decoder, let the field cable more unitary, bid farewell to the traditional network connection;

2. Customized version of one-way sealed watertight connector; pressure level up to 3000 meters,

3. Enjoy the warranty 1 year, life-long maintenance.

Main Parameter.png

Model No.	GLF-UDC-DN200
Image Sensor	1/2.8'' CMOS
Resolution	1920 x 1080
electronic shutter	1-1/30,000s
Digital zoom	16x
Video Format	AVI H.264
horizontal view angle	61.4-2.9 degrees (wide-angle telescope)
Sensitivity	Color: 0.05Lux @ (F1.6, AGC ON) BW: 0.01Lux @ (F1.6, AGC ON)
Minimum Focus Distance	10mm-80mm
Resolution and frame rate	50Hz:25fps(1920×1080),25fps(1280×720) 60Hz:30fps(1920×1080),30fps(1280×720)
LED Light Source	6pcs x 3W
Camera Size	φ335mm*370mm
Wire Type	Watertightness
Working Temperature	-10℃ ~ 60℃
Working Depth	0-100 meters
Interface type	RJ45
