The 45mm Dual (Side/Down) Rotation Camera Electric Cable Reel features an 8-inch underwater camera designed for versatile inspection with dual rotation capabilities, allowing both side and downward views. Equipped with a durable electric cable reel, it ensures efficient and reliable underwater monitoring in various environments.
Model No.: GLF-UDC-V8S45
Screen Size: 8 inch HD IPS LCD Screen
Camera Size: Ø45mm x 455mm
Cable Reel: 100m to 200m electrical winch
Applications: Deep wells, borehole ,water wells
Description
Products Description
Discover unparalleled underwater visibility with the Granfoo 45mm Dual-Rotation (Side/Down) Camera System. Featuring an 8-inch display and a motorized electric cable reel, this system is engineered for comprehensive underwater inspection and monitoring. Whether you are conducting marine research, overseeing underwater construction, or inspecting pipelines and ship hulls, the dual-rotation lens delivers crystal-clear, multi-angle visuals. Additionally, the integrated electric reel provides seamless cable management, reducing manual fatigue during extended underwater operations.
Overview of 45mm dual (side/down) underwater Camera
| Dia 45mm dual (side/down) camera |
| 1/3 CMOS, 1.3MP pilex AHD , waterproof IP68 |
| Adjustable focus function for side camera |
| 8 inch IPS icd screen,1980x1080 resolution |
| DVR control box with audio ,video recording and photography function |
| USB wireless keyboard to typewrite the words |
| Built in 10500mA li-ion battery inside |
| Digital meter counter function, error is less than 1% |
Product Details
| Camera size | 45mm x 420mm |
| Camera pixel | Sensor 1/3" CMOS, 1.3MP pixel |
| Waterproof level | Waterproof IP68 |
| Camera range | View range 120° |
| Focusing | Manual focus for side camera |
| Rotation range | Rotation: Pan 360°, Tilt 180° |
| Light | 6pcs high light LED lighting adjustable (side & down camera) |
| Connector | Detachable with aviation plug type connection to Cable Reel |
| Material | Lens window sapphire glass & stainless steel |
DVR control unit
| Screen Size | 8"HD IPS LCD Screen, 1980x1080 resolution |
| Waterproof level | Waterproof keys & waterproof panel |
| Function | Video, auido and photography function DVR |
| Keyboard | USB wireless Keyboard real time typewriting |
| Meter counter | Digital meter counter function, display on the screen |
| Battery | 10500mA rechargeable Li-ion Battery Pack |
| Battery level indicator |
Cable reel
| Meter counter | Digital meter counter |
| Material | Oxygen free copper flexible cable |
| Cable diameter | 8mm |
| Cable length | 100m-200m |
| Electric winding | Adjustable speed |
More Information
Deep Well Inspection Camera is a tool used to detect the conditions inside the borehole, which can help workers understand the conditions inside the borehole more accurately, and can save labor and reduce risks. When work such as drilling, mining or installing pipelines is required, the Deep Well Inspection Camera can provide very accurate and detailed information, thereby reducing the cost and danger of the work. There are mainly the following applications：
1. Geology: Deep well inspection cameras can be used to explore various subsurface formations to understand the geological and lithological distribution of various structures.
2. Civil Engineering: Deep well inspection cameras provide essential data for the evaluation of underground structural conditions.
3. Water conservancy and environmental engineering: used to monitor the internal conditions of water wells, underground water pipes, reservoirs, water pumps and other facilities.
4. Petroleum exploration: used to detect the conditions in oil wells and oil pipes.
5. Municipal construction: used to detect the internal conditions of sewers, drainage pipes, cable pipes, etc.
6. Coal mine and coalbed methane exploration: Deep Well inspection cameras can be used to explore the physical properties of various geothermal systems, can offer crucial insights into the rock mass quality and other structural features of mines, used to detect the distribution of underground coalbed methane and the condition of underground facilities.
