Factory Borehole Water Well Camera

Borehole Water Well Inspection Camera is a tool used for inspecting wells and boreholes. This camera has been designed with specific features that make it suitable for use in such conditions. The Borehole Water Well Inspection Camera can withstand harsh conditions, has high-quality imaging capabilities, and is easy to use.In many water wells and boreholes, it is essential to inspect the well's depth and the quality of water. Borehole Water Well Inspection Camera is used to inspect the well's lining and look for any damages or cracks that might cause the water to become contaminated. The Borehole Water Well Inspection Camera's high-quality imaging capabilities allow for clear images of the well's interior, revealing any issues that might be occurring.

Why We Choose Borehole Inspection Cameras?

1. Quick and Efficient Inspection
Using a borehole water well inspection camera can save time and increase efficiency when inspecting a well. The camera can easily navigate through the well, providing a clear visual representation of the interior. This makes it easier to diagnose any issues and identify potential problems that may require maintenance.

2. Accurate Diagnosis
The camera provides accurate visual feedback, allowing professionals to diagnose any issues that may be present. For instance, it can detect cracks, holes, and other defects in the well. This level of accuracy makes it possible to identify and address issues quickly and efficiently.

3. Detect Debris and Blockages
Debris and blockages in borehole wells are common issues that can affect the quality of water. Using a borehole water well inspection camera can help detect any debris or blockages in the well. This will help professionals to clear the debris and blockages, ensuring that the well is functioning optimally.

4. Cost-Effective
By detecting issues and addressing them promptly, the borehole water well inspection camera can help to prevent expensive repairs that may be required if issues are left unattended.

Camera Head

* Camera size: Φ50mm x 153mm

* Camera chip Aptina0130: 1/3 CMOS, 1.3MP 960P DSP: Nextchip2431

* Camera Lens 5G+IR650, M8

* Sensor: 1/3 inch HD CMOS 1.3MP pixel

* Sapphire lens protection glass

* Waterproof level: IP68 10bars

* Tilt angle: tilt 180º rotation, pan 360° infinite loop

* Camera angle: 120°

* Probe reset automatically

* 6 high-brightness LEDs, adjustable light

 DVR Control Unit

* 10 inch IPS screen, 1280X720 resolution

* PT rotating camera joystick

* HD video recording system, the video resolution is 720P

* Built-in character implantation system with USB Bluetooth keyboard

* Built-in digital counter, the error rate is less than 1%

* 3 video input interfaces

* Manual recording microphone key

* Audio, video output, with camera function

* Built-in rechargeable 8800mA lithium battery pack, which can support continuous work for 8 hours









Cable Reel

* Flexible coaxial cable 200m

* Cable diameter 7 mm

* Digital counter function, the error is less than 1%

* Cable length is optional from 100m to 200m (100m standard)

* Dimensions: 480*340(H)(L)*250(W)mm



A borehole camera is a specially designed camera system that is inserted into a borehole or well. The camera can then take pictures or video of the borehole walls and the surrounding formations. The camera system is mounted on a flexible cable that can be lowered into the borehole to capture images of the subsurface strata. By examining the images, geologists can gather information about the geological history of the area, identify mineral deposits, and locate underground water sources.

Borehole water well inspection cameras can be used in various applications, including:

1. Mineral Exploration: Borehole cameras are often used for mineral exploration. The images captured by the cameras help geologists to identify and locate mineral deposits beneath the surface of the earth. This information is crucial when planning mining operations as it helps to determine the quantity and quality of the minerals.

2. Engineering Projects: Borehole cameras are used in engineering projects to investigate the subsurface geology and conditions before construction begins. Engineers can use the data obtained from the borehole camera to determine the properties of the soil and rock, and make informed decisions about the design and construction of a project.

3. Groundwater Monitoring: Borehole cameras can be used to monitor groundwater resources. This is particularly useful in areas where groundwater levels are declining or where there is a risk of contamination. By analyzing the images obtained from the borehole camera, hydrologists can identify the flow patterns of groundwater and assess the quality of the water.

Borehole cameras are a valuable tool for geological exploration. With the ability to capture high-quality images of subsurface features, borehole cameras are a non-invasive and safe method of exploring the earth. They have several applications across various industries, including mineral exploration, engineering projects, and groundwater monitoring. By using borehole cameras, geologists can gather accurate and detailed information about the subsurface conditions and make informed decisions about resource management and environmental protection.

Our Certificates & Patents

CE Certificate

QA Certificate

Invention Certificate

    Shaanxi Granfoo Intelligent Technology is a High-tech intelligent enterprise, specialized in designing, R&D, manufacturing and exporting of underwater cameras, pipe inspection cameras, underwater inspection robot ROV, underwater connectors, underwater cables, water quality monitor muti-parameter sensor, etc. Granfoo has already been recognized as a strategic partner of many OEM businesses for about 16 years. We have the highly experienced team to work on your OEM projects. Our experience and splendid service have won us good business relationships with many international buyers and suppliers. Our products are sold to many countries across the world including Europe, North America, Japan, Korea, Australia, etc.

    We welcome you to become our next reseller or agent in your country. Our underwater camera systems are also apply to aquaculture, underwater exploration, reservoirs, dams, canals and other water conservancy facilities, construction and monitoring, wells, repair of oil wells, urban water supply network and the pipeline monitoring and maintenance, underwater sports research, the entertainment industry for underwater sightseeing, underwater weapons test monitoring and measurement, military facilities, underwater surveillance, recording and exploration of scientific research results, deep-sea salvage and oilfield operations and so on.
