1080P underwater 100M marine mornitoring with POE camera
1. Shell Compressive Standard Depth 300m
2. High Resolution 2 Megapixel
3. IP camera, ONVIF Compliant
Description
Marine monitoring with the underwater camera offers excellent opportunities for research in places that are inaccessible to humans. Video has many advantages over traditional diver-based monitoring, such as:
-
Observe life in parts of the ocean out of reach of divers
-
Create permanent records of observations for future reference and quality assurance
-
Reduce diver time in the water, reduce personal risk and increase sampling hours
-
Using images for artificial intelligence and automated data collection
Product Feature
1. Shell Compressive Standard Depth 300m
2. High Resolution 2 Megapixel
3. Standard H.264 video compression technology, accurate and stable code stream control
4. IP camera, ONVIF Compliant
5. Open SDK, support multiple network protocols and networking methods
6. Customized products according to different situations
Main Specifications
|
Model no. |
GLF-UDC-LI200-POM5X |
|
Image sensor |
1/2.9" CMOS sensor |
|
Resolution |
2 Megapixel |
|
Signal type |
Network |
|
Sensitivity |
0.1Lux@F1.2 (Color mode); 0.01Lux@F1.2 (Monochrome) |
|
Video processing |
H.265+/H.265X video coding, support dual stream, AVI format; support stream 0.1M~8Mpbs adjustable; support frame rate 1~30 frames/sec adjustable |
|
Image output |
Main stream: 1920*1080@20fps, 1280*720@25fps; substream: 704*576@25fps |
|
Network Interface |
1* RJ45 Ethernet interface, 10/100M adaptive; supports network protocols such as RTSP/FTP/PPPOE/DHCP/DDNS/NTP/UPnP |
|
Day and night mode |
Support IR-CUT |
|
Compatibility |
Supports ONVIF platform access such as Haikang, Xiongmai CMS, and Tianshitong UC2, and supports mainstream NVR ONVIF protocol access. |
|
Lens |
Standard 2.8mm-12mm automatic zoom lens |
|
Zoom |
Optical zoom 5x |
|
Function |
Support front-end storage playback/download; Support unified system remote monitoring software, platform, and other system applications; Provide a complete SDK development kit |
|
Housing material |
POM |
|
Waterproof level |
0-300 meters (max depth can be customized to 6000m) |
|
Power supply |
48VDC (customized can be 24V) |
|
Working temperature |
-20℃～+40℃ |
|
Storage temperature |
-30-60℃ |
|
Dimension |
Φ65*170mm (excluding 34mm connector) |
|
Weight in the air |
1.5 kg |
|
View angel |
90 degree |
|
Connector |
MCBH2MSS |
PLC Network Receiver:
|
Power input |
AC85V-245V 50/60HZ |
|
Power output |
DC48V |
|
Max current |
1.2A |
|
Max capacity |
220W |
|
Speed |
200Mbps |
|
Max distance |
600M |
|
Network port |
1*RJ45 |
|
Standard |
IEEE802.11a IEEE802.3u IEEE802.3ab |
|
Compatibility |
200Mbps 300Mbps |
|
Cable required |
>2*0.5² |
|
Shell material |
ABS |
|
Operating temperature |
-20℃-40℃ |
|
Operating humidity |
10%-90%RH |
|
Operating frequency |
1.8-30MHZ |
|
Dimension |
125*60*40mm |
Connecting:
Packing List:
1. Camera
2. 10m cable
3. PLC Receiver
If you want, please contact us: info@granfoo-cn.com
